Stretch Rack: 8010, 8080, 8018, 8016, 8110, 8180, 8118, 8116

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
8010		10	Stretch Rack		72x63x96"	72x63"
8080		8	Stretch Rack		72x63x96"	72x63"
8018		8	Stretch Rack		54x63x96"	54x63"
8016		6	Stretch Rack		54x63x96"	54x63"
8110		10	Stretch Rack-Locking		72x63x96"	72x63"
8180		8	Stretch Rack-Locking		72x63x96"	72x63"
8118		8	Stretch Rack-Locking		54x63x96"	54x63"
8116		6	Stretch Rack-Locking		54x63x96"	54x63"

COMPLETE QUOTE REQUEST

Vertical Rack: 8040, 8013, 8140, 8113

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
8040		4	vertical rack		72x45x80"	72x45"
8013		3	vertical rack - locking		54x45x80"	54x45"
8140		4	vertical rack		72x45x80"	72x45"
8113		3	vertical rack - locking		54x45x80"	54x45"

COMPLETE QUOTE REQUEST

6000 Series : Locking Bike Trac

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
6006		1	wall mount		N/A	N/A

COMPLETE QUOTE REQUEST

6003T : Bike Trac

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
6003T		1	wall mount		N/A	N/A

COMPLETE QUOTE REQUEST

2400 Series : Post and Ring

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
2452		2	below grade	27 lbs.	21” x36”x 1.5”	68” x 110”
2451		2	flangemount	21 lbs.	21” x32.7”x1.5”	68” x 110”

2.5”x1.5” .188” heavy duty structural grade tubing.
1 yr. manufacturer’s warranty.
Available in Below Grade or Flange Mount (anchored with #6260 spike anchor kit, sold separately).
Ships via common carrier.

COMPLETE QUOTE REQUEST

6900 Series : Bike Dock

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
6902		2	below grade		34” x 2”x 36”	68” x 20”
6903		2	flangemount	23 lbs.	30” x 6”x 36”	68” x 20”

Materials
Frame: 1.66” O.D. -- 12 gauge electric-welded tubing
Finish: Electroplated in a chromate solution with ultra seal

COMPLETE QUOTE REQUEST

2100 Series : Centurium Bike Dock

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
2112		2	below grade	40 lbs.	34” x 2.4” x 36”	68” x 110”
2113		2	flange mount	35 lbs.	34” x 6” x 36”	68” x 110”

Materials
2x2-in square tubing with 7-guage 3/16-in. wall.

COMPLETE QUOTE REQUEST

2200 Series : Bike Dock

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
2212		2	below grade	38 lbs.	30” x 2.4” x 32”	68” x 110”
2213		2	flange mount	34 lbs.	34” x 6” x 32”	68” x 110”

Materials
2 3/8" — schedule 40 steel pipe, 9 gauge

COMPLETE QUOTE REQUEST

2100 Series : Millenium Wave

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
2102		5	below grade mount	57 lbs.	57”x2.4”x36”	87” x 110”
2103		5	flange mount	60 lbs.	60”x6”x36”	87” x 110”
2105		7	below grade mount	90 lbs.	93”x2.4”x36”	123” x 110”
2106		7	flange mount	95 lbs.	96”x6”x36”	123” x 110”
2108		9	below grade mount	108lbs.	129”x2.4”x36”	159” x 110”
2109		9	flange mount	111 lbs.	132”x6”x36”	159” x 110”

COMPLETE QUOTE REQUEST

2160 Series : Wave

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
2160		13	below grade mount	145 lbs.	137”x4”x48”	167” x 110”
2161		13	flange mount	142 lbs.	141”x8”x38”	167” x 110”
2162		5	below grade mount	52 lbs.	48”x3”x40”	66” x 110”
2163		5	flange mount	50 lbs.	46”x8”x37”	66” x 110”
2164		7	below grade mount	74 lbs.	65”x3”x49”	92” x 110”
2165		7	flange mount	72 lbs.	69”x8”x38”	92” x 110”
2166		9	below grade mount	96 lbs.	88”x3”x49”	116” x 110”
2167		9	flange mount	94 lbs.	94”x8”x38”	116” x 110”
2168		11	below grade mount	119 lbs.	112”x3”x49”	142” x 110”
2169		11	flange mount	145 lbs.	118”x8”x38”	142” x 110”

Materials
Heavy duty 2-3/8-in. schedule 40 pipe.

COMPLETE QUOTE REQUEST

2200 Series : Wave

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
2202		5	below grade mount	76 lbs.	80”x2”x36”	107” x 110”
2203		5	flange mount	76 lbs.	84”x6”x36”	111” x 110”
2205		7	below grade mount	111 lbs.	132”x2”x36”	159” x 110”
2206		7	flange mount	114 lbs.	136”x6”x36”	163” x 110”

Materials
2x2-in. square tubing.
7-guage 3/16-in wall.

COMPLETE QUOTE REQUEST

6800 Series : Wave

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
6802		5	below grade mount	32 lbs.	32”x2”x36”	68” x 110”
6803		5	flange mount	38 lbs.	36”x6”x36”	68” x 110”
6804		7	standard leg mount	56 lbs.	52”x29”x36”	92” x 110”
6805		7	below grade mount	43 lbs.	52”x2”x36”	92” x 110”
6806		7	flange mount	49 lbs.	56”x6”x36”	92” x 110”
6808		9	below grade mount	58 lbs.	72”x2”x36”	116” x 110”
6809		9	flange mount	67 lbs.	76”x6”x36”	116” x 110”

Materials
Frame: 1-5/8” O.D. -- 12 gauge electric-welded tubing
Finish: Black double-coated polyester

COMPLETE QUOTE REQUEST

6200 Series : Commercial Duty Park-A-Bike

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
Double-sided units
6201 :		18 (9 each side)	standard leg mount	108 lbs.	110” x 43” x 31”	110” x 126”
6205 :		10 (5 each side)	standard leg mount	66 lbs.	60” x 43” x 31”	60” x 126”
Single-sided units
6203 :		9	standard leg mount	92 lbs.	110” x 28” x 31”	110” x 72”
6207 :		5	standard leg mount	57 lbs.	60” x 28” x 31”	60” x 72”
Add-on kit
6206 :		-	collar sections	3 lbs.
6208 :		-	collar sections	3 lbs.

Materials
Frame and end sections: 1-5/8” O.D. -- 14 gauge electric welded tubing
Vertical wheel slots: 14 gauge x 3/4” O.D. electric welded tubing
Finish: Electroplated in a chromate solution with ulta seal

COMPLETE QUOTE REQUEST

6400 Series : L.E. Series

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
Double-sided units
6401		18 (9 per side)	standard leg mount	91 lbs.	110”x39”x31”	110” x 127”
6405		10 (5 per side)	standard leg mount	57 lbs.	60”x39”x31”	66.5” x 127”
Single-sided units
6403		9	standard leg mount	92 lbs.	110”x25”x31”	110” x 71”
6407		5	standard leg mount	57 lbs.	60”x25”x31”	66.5” x 71”

Materials
Frame and end sections: 1.66” O.D. 14 gauge electric-welded tubing
Vertical wheel slots: 14 gauge x 3/4” O.D. electric-welded tubing

COMPLETE QUOTE REQUEST

6210 Series : Mighty Mite

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
6210		6	double-sided	27 lbs.	35”x33”x22.5”	35” x 124”

Materials
Frame: 1” O.D. -- 16 gauge electric-welded tubing
Vertical wheel slots: 3/4” O.D. 16 gauge electric welded tubing
Finish: Double-coated polyester, black

COMPLETE QUOTE REQUEST

6901 Meter Ring

Model #	Qty.	# of bikes	Description	Weight	L x W x H	Footprint w/bikes
6901		2	mounts on 2 3/8” meter post	5 lbs.	18”x3.5”x17”	68” x 110”

Materials
Strong aluminum composite.
Finished in double-coat polyester TGIC coating (standard color grey).
Stainless steel tamper-proof hardware and tool included.

COMPLETE QUOTE REQUEST
